Fiber and Ethernet Test Equipment

       The Jonard Tools OFI-50 Optical Fiber Identifier is a must-have tool for network professionals seeking efficient and non-disruptive fiber identification. Designed to quickly and accurately identify the direction of transmitted fiber and display relative core power, this optical fiber identifier enhances network maintenance without causing any damage to the fiber. Key Features: Direction Identification: With easy one-key operation, this tool efficiently identifies the traffic direction and frequency tone (270Hz, 1KHz, 2KHz) with audible warnings, making it a valuable asset for network troubleshooting. Clear Display: The intuitive display provides a clear view of the relative core power, ensuring accurate readings for better network management. Versatile Adapters: The kit includes a range of adapters (3 mm, 2 mm, 900 nm, and 250 nm) to accommodate various fiber optic cable sizes, offering versatility in usage. Sunshade Protection: The included sunshade protects the fiber optic cable from interference, ensuring precise readings even in challenging environments. Durable Construction: Housed in a rugged metal casing, this optical fiber identifier is built for long life and durability, withstanding the demands of professional use. Battery Indicator: Stay informed about battery status with the LED indicator, so you can replace the 9V battery as needed to keep your tool running smoothly. Technical Specifications: Identified Wavelength Range: 800-1700 nm Identified Signal Type: CW, 270Hz±5%, 1kHz±5%, 2kHz±5% Detector Type: Ø1mm InGaAs 2pcs Adapter Type: Ø0.25 (Applicable for Bare Fiber), Ø0.9, Ø2.0, and Ø3.0 Signal Direction: Left & Right LED Signal Direction Test Range: -46~+10 dBm (1310 nm, CW/0.9 mm bare fiber), -50~+10 dBm (1550 nm, CW/0.9 mm bare fiber) Signal Frequency Display: 270 Hz, 1 kHz, 2 kHz Insertion Loss: 0.8 dB (1310nm), 2.5 dB (1550nm) Battery Type: 9V Kit Includes: Fiber Identifier, 3 mm, 2 mm, 900 nm, and 250 nm adapters, sunshade, and a convenient carrying pouch.      Discover the Jonard Tools OFI-50 Optical Fiber Identifier and take your network troubleshooting to the next level with this efficient and reliable tool.

Read more less

Triplett LVPRO40 10 Gb Multifunctional Low Voltage Cable / Network Tester Overview The Triplett LVPRO40 is a high-performance, all-in-one cable and network tester tailored for today’s advanced LAN installations and diagnostics. This professional-grade tool supports thorough testing of both twisted-pair (Cat 5E/6/6A/7) and coaxial cables, offering fault detection, TDR length measurement, PoE analysis, Ethernet switch diagnostics, and more. Tri-Tek Electronics, with its Mesa, AZ retail presence, offers this model with complete manufacturer warranty coverage, competitive pricing, and expert factory support. Key Features Multi-Cable Support: Tests twisted-pair (UTP/FTP/SSTP Cat 5E-7), coax (50Ω, 75Ω, 93Ω), telephone, speaker, and alarm cables. Comprehensive Fault Detection: Identifies opens, shorts, reversals, split pairs, and provides wiring diagnostics including wiremap, skew, delay, and resistance measurements. Accurate TDR Length Measurement: Measures cable length up to 1999 ft (610 m) with 1.5 ft resolution; adjustable velocity-of-propagation (VOP) and return-loss quality (RLQ) provided. Advanced Network & PoE Analysis: Detects network speeds (10M/100M/1G/10G) and cable pairs in use; reports PoE presence (802.3AF, AT, BT), CCTV, CATV, and loaded-battery test readings. Switch Port Blink & Remote Testing: Includes port blink function to locate switch ports; smart RJ45 remotes allow simultaneous testing of up to 8 cables. Tone Generation & Reporting: Built-in tone generator for tracing; stores and prints up to 250 test results. User-Friendly Display: Bright 2.8″ backlit graphical LCD ensures clarity in any lighting condition. Durability & Convenience: Auto power-off, 70 VDC input protection, compact form factor (~7.1 × 3.2 × 1.5 in, 9.2 oz), powered by three (3) AA batteries. Specifications Specification Details Cable Types Tested UTP/FTP/SSTP Cat 5E–7; coax (50/75/93Ω); telephone, speaker, alarm cables Fault Diagnostics Opens, shorts, reversals, split pairs, wiremap, skew, delay, ohms Cable Length & Accuracy Up to 1999 ft (610 m); resolution: 1.5 ft (0.5 m); accuracy: ±(2% + 3 ft/1 m) Adjustable VOP & RLQ Yes Network Speed Detection 10M/100M/1G/10G PoE Detection 802.3AF, 802.3AT, 802.3BT Signal Testing CCTV (peak-to-peak volts), CATV (min 30 mV), battery 100 mA loaded test Reporting Store & print up to 250 reports Switch Port Blink Yes Tone Generator Yes Display 2.8″ backlit graphical LCD Power Protection 70 VDC input protection Power Source 3 × AA batteries Dimensions & Weight 7.1 × 3.2 × 1.5″ (181 × 81 × 37 mm); 9.2 oz (260 g) Warranty 1 year manufacturer warranty Included in the Box LVPRO40 Main Tester Eight (8) RJ45 Smart Remotes USB Cable RJ45-to-RJ45 Connector Cable RJ45 Cable with Alligator Clips Three (3) AA Batteries Example Installation Scenario In a multi-drop network deployment, an installer can: Simultaneously test eight cables using smart remotes—great for mass deployments or wall-jack labeling. Determine cable quality and length via TDR, detecting any faults or discontinuities. Verify PoE delivery and network port capability before equipment installation. Locate switch ports quickly using the port blink function. Trace specific cable runs efficiently using the built-in tone generator. Archive test missions, storing data on up to 250 runs for compliance or record-keeping—all on a single, lightweight handheld. The LVPRO40 streamlines workflows, reduces tool clutter, and enhances diagnostic capability—making it indispensable for system integrators, installers, and field network professionals.

Read more less

Triplett LVPRO10 TDR/Cable Tester Overview The Triplett LVPRO10 is an all-in-one TDR (Time Domain Reflectometry) cable tester designed for LAN installers, network technicians, and repair professionals. It delivers comprehensive diagnostics for both twisted-pair and coaxial cables, combining precision fault detection, tracing, and PoE analysis into a single, rugged handheld device. Tri-Tek Electronics, located in Mesa, AZ, proudly offers this model with full manufacturer warranty, competitive pricing, and expert factory support—ensuring a reliable tool for installers and technical professionals. Key Features Dual Cable Support: Tests and traces UTP twisted-pair (Cat 5E/6/6A/8) and coaxial (50Ω, 75Ω, 93Ω) cables with high accuracy. Fault Diagnostics: Identifies opens, shorts, reversals, split pairs, and verifies cable continuity. Length Measurement: Measures cable length up to approximately 500m (1,640 ft) with ±4% or ±2 ft (0.6 m) accuracy. PoE Detection & Ethernet Port Testing: Detects Power over Ethernet (standards 802.3AF, AT, BT) and validates port functionality via Ethernet analysis. Tone-Tracing Capability: Includes a tone mode to trace specific cables within bundled runs. Built-In Ports & Display: Equipped with RJ11, RJ45, and coax connectors and a 2.8-inch backlit graphical LCD for clear readings in all conditions. Safety & Convenience: Features 70 VDC protection, auto power-off, and a tracer probe with NCV detection (> 40 V), flashlight, wiremap indicators, low-battery alert, and headphone jack—ideal for noisy or dim environments. Download LVPRO10 User Manual (.pdf) Specifications Specification Details Cable Types Twisted-pair (Cat 5E/6/6A/8), Coax (50/75/93Ω) Fault Detection Continuity, opens, shorts, reversals, split pairs Length Range & Accuracy Up to 500 m (1,640 ft); ±4% or ±2 ft (0.6 m) PoE Detection 802.3AF, 802.3AT, 802.3BT Ports RJ11, RJ45, Coax Display 2.8″ backlit graphical LCD Safety Features 70 VDC input protection; auto power-off Tracer Probe Features NCV detection > 40 V, flashlight, indicators, earphone jack Power Requires 4 × AAA batteries (included) Accessories Included Tracer probe with charging cable, remote adapter, RJ11/RJ45 cables, alligator RJ11 cable, F-to-F adapter, carrying bag Warranty 1-year manufacturer warranty Weight (approximate) ~1.2 lbs Included in the Box LVPRO10 Tester (Remote & Receiver) Tracer probe with charging cable Remote adapter RJ45 and RJ11 adapter cables RJ11 cable with alligator clips F-to-F-connector adapter Four (4) AAA batteries Carrying bag Usage Scenario Example During structured cabling installation in a commercial office, the LVPRO10 simplifies troubleshooting and verification: Trace the intended cable within crowded conduit runs using tone mode and the tracer probe. Validate cable health and length via TDR measurements to ensure run integrity. Detect PoE presence on Ethernet drops to verify power supply capability before equipment install. Confirm port wiring and detect any miswiring, reversals, or split-pair faults in under a minute. Operate in dimly lit junction boxes using the built-in flashlight and get audio feedback through the earphone jack in noisy environments. This single handheld tool reduces job site complexity, expedites diagnostics, and ensures reliable network infrastructure deployment—ideal for technicians, installers, and field service teams.

Read more less

Triplett CTX1200 Network & Cable Tester with Probe The Triplett CTX1200 is a versatile, professional-grade tester ideal for network cabling installations, maintenance, computer room diagnostics, and CCTV deployment. It combines advanced TDR diagnostics, network analysis, cable tracing, and video level measurement into a single, portable unit—designed to streamline job site efficiency and accuracy. Tri-Tek Electronics, with its retail presence in Mesa, AZ, provides this product with full manufacturer warranty support, competitive pricing, and reliable factory support. Key Features Built-in TDR (Time Domain Reflectometry): Measures opens, shorts, and length up to 1.2 km on UTP, Cat 5e/6e, BNC, and telephone lines. 2.4″ TFT-LCD: High-resolution 320×240 pixel display for clear, easy readability. Network Tools Suite: Ping testing Port flashing IP address scanning Identifies network port speed (10/100/1000 M) and duplex mode (full/half) Cable Tracing & Identification: Traces UTP and BNC cables in bundles “Secondary code” digital mode reduces false signals and improves accuracy RJ45-Specific Diagnostics: Tests cable pair status, length, attenuation, reflectivity, impedance, skew (up to 180 m) Detects fault points at the connector (near/mid/far-end) HD Coaxial Video Level Meter: Measures peak, sync, and burst values for TVI, CVI, AHD, and CVBS video signals Download CTX1200 User manual (.pdf) Specifications Specification Details Display 2.4″ TFT-LCD, 320 × 240 resolution Cable Types Tested RJ45 UTP, RJ11 telephone line, BNC TDR Range Opens, shorts, length up to 1.2 km RJ45 Diagnostics Pair status, length, attenuation, reflectivity, impedance, skew up to 180 m Network Analysis Features Port flashing, ping, IP scan, speed & duplex detection Video Signal Meter TVI/CVI/AHD/CVBS peak, sync, burst values Dimensions 5 × 3.3 × 1.3″ (126 × 83 × 33 mm) Weight 0.75 lbs (340 g) Power Supply 3.7 V Li-ion battery (included) or 5 V/1 A AC adaptor Tracer Probe Power 2× AA batteries (not included) Warranty 1 year manufacturer warranty Included in the Box Triplett CTX1200 tester with probe 3.7 V Li-ion battery AC adaptor/charger BNC to alligator clip adapter RJ11 and RJ45 patch cables Cable tracer unit Tool bag Example Usage Scenario During a CCTV camera installation at a commercial building, the CTX1200 enables a technician to: Trace the correct BNC cable in a dense cable bundle using the cable tracer. Test cable integrity and length via the built-in TDR to verify performance up to 1.2 km. Analyze the video signal (TVI/AHD) levels using the video level meter to ensure video quality and correct signal levels. Validate network configurations by pinging connected IP cameras and identifying IP addresses, link speed, and duplex settings—all from the same handheld device. This one-tool solution saves time, reduces equipment needs, and improves installation reliability—perfect for network installers, CCTV technicians, and IT professionals.

Read more less

Jonard Tools TDR-100 Network Cable Tester and TDR The Jonard Tools TDR-100 is a versatile, field-ready tester that combines a time-domain reflectometer (TDR) with a standard network cable tester. Designed for network engineers, IT professionals, and low-voltage technicians, it quickly identifies cable faults, measures cable length up to 400 m (1,312 ft), and traces installed cabling with an integrated tone generator. The 2.5″ color LCD and built-in flashlight ensure clear readings even in dimly lit patch panels or conduit runs. As an authorized distributor, Tri-Tek Electronics provides full manufacturer warranty coverage, the best pricing, and direct factory support from our Mesa, AZ retail location. Key Features: TDR Measurement: Pinpoints cable breaks or faults and measures length from 6.6 ft to 1,312 ft (2 m–400 m) Wire Pair Mapping: Verifies TIA-568A/B line sequence; detects opens, shorts, crossed pairs, and reversals Cable Tracing: Functions as a tone generator to locate and trace cables behind walls or in bundles using the included probe Display & Lighting: 2.5″ TFT color LCD for clear diagnostics; probe features a built-in flashlight for low-light environments Durable Design: Compact housing with ergonomic grips, ideal for field and rack-room use Includes: Jonard Tools TDR-100 Cable Tester and TDR unit Cable Tracing Probe RJ45 Adapter Cable Rugged Carrying Case Six (6) AAA Batteries Specifications: Cable Length Range: 6.6 ft–1,312 ft (2 m–400 m) Working Temperature: 0 °C–40 °C Storage Temperature: –10 °C–50 °C Display Type: 2.5″ TFT color LCD Power Supply: Six (6) AAA batteries Dimensions (HxWxD): 8.98″ × 5.63″ × 2.12″ (22.8 × 14.3 × 5.4 cm) Weight: 1.05 lb (477 g) UPC: 810132438141 Example Usage ScenarioA data-center technician uses the TDR-100 to validate newly pulled Cat6A runs across multiple server racks. After terminating and labeling each cable, the technician clamps the RJ45 adapter, selects TDR mode to confirm run lengths, then switches to tone mode to trace cables through wall-mounted conduits—eliminating guesswork and reducing downtime. Tri-Tek Electronics, your local Mesa, AZ supplier, ensures every TDR-100 purchase includes full manufacturer warranty coverage, factory-direct technical support, and competitive pricing for Phoenix-area installers, hobbyists, and technicians.

Read more less

Platinum Tools PT-OTDR-100 Mini SM Fiber and Copper OTDR 1310/1550 The Platinum Tools PT-OTDR-100 is a compact, multifunctional Optical Time Domain Reflectometer (OTDR) designed for both single-mode fiber and copper cable testing. With its dual-wavelength capability (1310nm and 1550nm), this device offers a comprehensive solution for field technicians, network engineers, and installers requiring precise diagnostics and fault localization in fiber optic and copper networks. Key Features Dual-Wavelength OTDR Testing: Supports 1310nm and 1550nm wavelengths with dynamic ranges of 26dB and 28dB, respectively. Comprehensive Testing Range: Measures fiber lengths from 3 meters up to 105 kilometers. Integrated Tools: Visual Fault Locator (VFL): 10mW 650nm laser for pinpointing fiber breaks. Optical Power Meter (OPM): Measures wavelengths at 850, 1300, 1310, 1490, 1550, and 1625nm. Light Source (LS): Provides stable outputs at 1310nm and 1550nm. Copper Cable Testing: Includes RJ45 remote for continuity and Time Domain Reflectometry (TDR) length measurements up to 600 meters. User-Friendly Interface: 5.5-inch OLED touchscreen with 1280x720 resolution for clear visualization. Data Management: Test results exportable in SOR, PDF, or Excel formats. Rugged Design: Compact and durable, weighing only 1 lb (0.45 kg), suitable for field conditions. Battery Life: Built-in 4000mAh Li-ion battery offering up to 5 hours of continuous operation. Technical Specifications Download PT-OTDR-100 Specifications Sheet (.pdf) Download PT-OTDR-100 User Manual (.pdf) Specification Details Wavelengths 1310nm / 1550nm Dynamic Range 26dB (1310nm) / 28dB (1550nm) Pulse Widths 5ns to 20µs (selectable) Event Dead Zone ≤1.6 meters Attenuation Dead Zone ≤8 meters Distance Accuracy ±(1m + 5×10⁻⁵ × distance + sampling interval) Storage Capacity 8GB internal flash + TF card support Interface Type SC-UPC Operating Temperature -10°C to +50°C (14°F to 122°F) Dimensions 183mm x 110mm x 36.5mm (7.2in x 4.33in x 1.43in) Weight 0.45 kg (1 lb) Installation and Usage Scenario Ideal for field technicians conducting installations or maintenance of fiber optic networks, the PT-OTDR-100 allows for rapid identification of faults such as breaks, bends, or splices. For example, during the deployment of a new single-mode fiber link between two network nodes, a technician can use the PT-OTDR-100 to verify the integrity of the fiber, ensuring there are no faults or excessive losses before the network goes live. Additionally, the device's copper testing capabilities make it suitable for verifying Ethernet cabling in data centers or office environments. Tri-Tek Electronics, located in Mesa, AZ, is an authorized distributor of Platinum Tools products. Purchasing from Tri-Tek ensures full manufacturer warranty coverage, competitive pricing, and direct factory support. Our retail location serves the Phoenix metropolitan area, including Mesa, Chandler, Tempe, Gilbert, Scottsdale, and Glendale.

Read more less

Jonard Tools WFM-100 Wireless Fiber Inspection Microscope Tri-Tek Electronics is proud to offer the Jonard Tools WFM-100 Wireless Fiber Inspection Microscope, a high-performance, portable device designed for precision end-face inspection of fiber optic connectors. As an authorized distributor, Tri-Tek Electronics ensures full manufacturer warranty coverage, best pricing, and factory-backed support for all Jonard Tools products. The WFM-100 is engineered for technicians and fiber installers requiring clear, high-resolution imaging in the field. It wirelessly transmits real-time inspection data to mobile devices using a dedicated app and also supports USB-C direct connection to OTDRs and other compatible equipment. This tool eliminates guesswork in fiber cleanliness by providing automatic pass/fail analysis, making it ideal for certification and troubleshooting in data centers, telecom environments, and field installations. Download Jonard Tools WFM-100 Product Specifications (.pdf) Features and Benefits: Wireless Connectivity: Built-in Wi-Fi module transmits live images to iOS and Android devices via the Jonard FiberScope app 200x Magnification: Enables clear visualization of connector end-faces for detailed inspection High-Resolution Imaging: Captures at 1280 x 1024 resolution with 0.75 μm lens resolution for exceptional clarity Auto Analyze Function: Automatically detects and evaluates connector cleanliness, displaying instant pass/fail reports Multiple Adapter Tips: Includes SC/ST/FC and LC male/female tips for broad compatibility USB-C Interface: Allows for tethered connection with compatible OTDRs and other test equipment Rechargeable 3000 mAh Battery: Provides up to 3 hours of continuous inspection Long-Range Operation: Maintains wireless connection up to 100 meters (328 feet) from the inspection device Technical Specifications: Specification Details Magnification 200x Image Resolution 1280 x 1024 Lens Resolution 0.75 µm Focus Range 4 mm Battery Capacity 3000 mAh Battery Life Approx. 3 hours continuous use Wireless Range Up to 100 m (328 ft) Connectivity Wi-Fi + USB-C Supported Devices Android, iOS, and USB-C platforms Dimensions 9" x 7.25" x 3.3" (22.86 x 18.42 x 8.38 cm) Weight 1.5 lb (680 g) UPC 810132437595 Installation/Usage Scenario: A fiber technician working in a high-density telecom facility can quickly connect the WFM-100 to their smartphone, inspect dozens of fiber ports, and automatically receive pass/fail results for each connection. This drastically reduces inspection time and ensures optimal signal performance across the network. Whether you're a fiber optic installer needing reliable inspection in the field or a technician maintaining a large fiber infrastructure, the Jonard WFM-100 delivers efficiency, accuracy, and convenience in a compact, rugged form factor. Visit Tri-Tek Electronics at our retail location in Mesa, AZ or shop online for fast, local service and expert support.

Read more less

Triplett RWV10G Real World LAN and Cable Verifier The Triplett RWV10G Real World LAN and Cable Verifier is a cutting-edge tool that elevates cable and network verification to new heights. Unlike traditional testers, it employs digital circuitry and testing techniques to deliver comprehensive analysis for both unshielded twisted pair (UTP) and Ethernet devices.  Features: Comprehensive Cable Testing: Performs TIA568 cable verification, including length measurement, detection of opens, shorts, split pairs, and wire mapping for UTP cables. Speed and Category Assessment: Evaluates UTP cables to determine their category (CAT3, CAT5, CAT5E, CAT6, CAT7) and speed capabilities (10M, 100M, 1G, 10G). Live Network Device Testing: Interfaces with network devices such as hubs, switches, and PCs to test UTP cables under live data conditions, analyzing links and data across various equipment. High-Resolution Timing Analysis: Equipped with an engine capable of 1-nanosecond resolution, ensuring precise measurement of cable parameters. Coaxial Cable Testing: Supports testing of coax cables for length, opens, shorts, wire mapping, and distance to faults, enhancing its versatility. Data Storage: Capable of storing up to 250 test results for subsequent analysis and reporting. Specifications: Parameter Specification Cable Types Supported UTP (unshielded twisted pair) and coaxial cables Speed Testing Capabilities 10M, 100M, 1G, 10G Display Full-color interface for clear visualization of test results Included Accessories Remote Probe, (2) RJ45 to RJ45 cables, RJ45 to F cable, USB cable, (1) 9V and (3) AA batteries Battery 3*1.5V AA Battery Operating Temperature 0 to 50°C (32 to 122°F) Storage Temperature -10 to 60°C (14 to 140°F) Humidity 80% max Altitude 2000 meters Pollution Degree 2   Example Usage Scenario: In a large-scale network deployment within a corporate office in Phoenix, AZ, a technician can utilize the RWV10G to verify the integrity and performance of installed Cat 6A cables. By conducting comprehensive tests, including speed verification up to 10G, the technician ensures that the network infrastructure meets the required standards for high-speed data transmission. This process is crucial for preventing potential connectivity issues and optimizing overall network performance. Tri-Tek Electronics, located in Mesa, AZ, is an authorized distributor of Triplett products. Purchasing from Tri-Tek ensures full manufacturer warranty coverage, competitive pricing, and access to factory support. Local customers in the Phoenix metropolitan area, including Mesa, Chandler, Tempe, Gilbert, Scottsdale, and Glendale, can benefit from Tri-Tek's expertise and support for all their networking needs.

Read more less

Eclipse MT-7615 4-in-1 Fiber Optic Power Meter The Eclipse MT-7615 4-in-1 Fiber Optic Power Meter is an essential tool for field technicians working with fiber optic networks. This versatile device combines four key functions into a single, compact unit, providing the ability to measure optical power, test cable lengths, locate faults with its Visual Fault Locator (VFL), and perform self-calibration. The device supports a broad wavelength range from 850nm to 1625nm, making it highly versatile for various fiber optic applications, including installations and maintenance. It features 500 data storage slots and is powered by a rechargeable lithium-ion battery, ensuring long-lasting performance. Key Features: 4-in-1 Functionality: Power meter, cable length tester, VFL, and self-calibration. Wide Measurement Range: Covers wavelengths from 850nm to 1625nm. Visual Fault Locator: Helps quickly identify fiber breakpoints and faulty connections. Rechargeable Battery: Lithium-ion battery provides convenience and extended usage. Compact and Portable: Easy to carry for on-site inspections. This power meter is perfect for network installations, troubleshooting, and fiber optic maintenance, offering reliable performance in a durable design fiber

Read more less

Jonard Tools FPM-50S Fiber Power Meter Description:The Jonard Tools FPM-50S Fiber Power Meter is a professional-grade tool designed for testing the signal strength and power in fiber optic networks. This instrument is essential for technicians in the field of fiber optics, providing accurate measurements and ensuring optimal performance of fiber networks. Features: High precision measurement capabilities for accurate power readings Compatibility with various types of fiber optic cables User-friendly interface for ease of operation Durable construction suitable for field use Specifications: Wavelength Range: 850, 980, 1270, 1300, 1310, 1490, 1550, 1577, 1625, 1650 nm, ≤ ± 0.2 dB Power Measurement Range: -50 dBm to +26 dBm resolution: 0.01 dB Connector Type: FC (APC/PC/UPC) & LC (PC/UPC) Installation Scenario:The FPM-50S is ideal for use in setting up and maintaining fiber optic networks in commercial buildings. For instance, during the installation of a new fiber network in an office building, the FPM-50S can be used to measure the power levels at different points, ensuring that the network is functioning at its optimal capacity. Additional Information:Tri-Tek Electronics is an authorized distributor of the Jonard Tools FPM-50S Fiber Power Meter. Customers purchasing from Tri-Tek Electronics are guaranteed full manufacturer warranty coverage, competitive pricing, and excellent factory support.

Read more less

Pro'sKit MT-7501E Fiber Optic Visual Fault Locator for FC/SC/ST Portable, durable and easy to use Support 2.5mm universal connectors (for FC/SC/ST) Dust-proof & crash-proof cap design for laser head Product Specifications Wavelength 650 nm±10 nm Output  1mW Laser class CLASS II Tested fiber length  3-5km Power AA (1.5 V) x 2 Connector 2.5mmFC/ST/SC connector OAL 7 in. Operation temp. -10~55°C Storage temp. -10~70°C Optional accessory LC1.25mm adaptor(5MT-7601-LC)

Read more less

Jonard Tools, FPM-50A, Fiber Optic Power Meter With VFL-25125 Measures a wide variety of wavelengths from 800-1650 nm, with a mere 0.01 dB resolution Measures 6 preset calibrated wavelengths with high precision to determine absolute or relative power Special function of the unit allows the device to be manually calibrated as needed LED screen is backlit for viewing in low light locations and a 10 minute auto-off helps preserve battery life Dust-proof button design and shatter-resistant sleeve protect the tool to last a lifetime Comes with FC, SC, and LC adapters so that fiber connectors can be directly connected to the tool The FC/SC adapters are for APC/PC/UPC connectors The LC adapter is for PC/UPC connectors only Includes: Fiber Optic Power Meter Instruction Manual Protective Cover (3) AA Batteries (required for operation) (2) Cleaning Swabs FC Adapter LC Adapter SC Adapter Nylon Carry Case

Read more less
