Push Button Circuit Breakers

Philmore B7005, 5 Amp Push Button Circuit Breaker 32v DC or 250v AC Fuse "B7000" series circuit breakers are UL 1007 recognized as Supplementary protectors (File E99607) and CSA certified as appliance components protectors (File LR62590). B7000 series are single pole, thermal circuit breakers that feature a recessed reset button which cannot be manually pulled out to disconnect the circuit. When an overload occurs and the breaker opens, it allows the reset button to "pop out" for visible trip indication.   Amps: 5 Max. Resistance: .026 ohms Trip time @ 200% of Rating: 10-45 seconds   Specifications: Input Power: 125 VAC / 250 VAC / 50 VDC Dielectric Strength: 1500 VAC / 1 Minute Interrupt Capacity: 125 VAC x 1000 A, 250 VAC x 2000 A Insulation Resistance: > 100 M Calibration: 25 C-100% of rated current continuously carried 25 C-between 101% to 145% - may trip or not 25 C-150% of rated current - trip within 1 hour 25 C-200% of rated current - trip within 1 minute Contact Endurance: 125 VAC x 150% of rated current - 500 cycles 3A -50A: Spade Terminals 60A - 90A: Screw Terminals

Read more less

Philmore B7008, Circuit Breaker Thermal 1 Pole 8A 250VAC 2-Pin B7000 Series PUSH BUTTON THERMAL CIRCUIT BREAKER B7000 Series breakers are UL 1077 Recognized as Supplementary protectors, File E99607, and CSA Certified as appliance Components protectors, File LR62590. B7000 Series are single pole, thermal circuit breakers that features a recessed reset button which cannot manually pulled out to disconnect the circuit. When overload occurs and the breaker opens, it allows the reset button to pop out for visible trip indication. Endurance: 1,000 times at least Calibration: Breaker will continuously carry 100% of rated load. It may trip between 101% and 144% of rated load, but must trip at 145% at 25 C. Dielectric Strength: Over 1,500 volts RMS. Max. Operating Voltages: 50VDC, 250VAC Interrupt Capacity: 2,000 Amps, at 50 VDC(1-30 amp Models) 1,000 Amps, at 250VAC (1-30 amp Models)Manufactured by:Philmore LKGMerchant SKU:B7008

Read more less

Philmore B7010, Push Button Thermal Circuit Breaker - 10 Amp B7000 series circuit breakers are UL 1077 Recognized as Supplementary protectors, File E99607, and CSA Certified as appliance components protectors, File LR62590. B7000 Series are single pole, thermal circuit breakers that feature a recessed rest button which cannot be manually pulled out to disconnect the circuit. When an overload occurs the breaker opens, it allows the rest button to "pop out" for visible trip indication. Specifications: Current Rating: 10A@Max resistance in ohms: .014Trip time @ 200% of rating: 6-30 seconds Endurance: 1,000 times +Calibration: Breaker will continuously carry 100% of rated load. It may trip between 101% and 144% of rated load, but must trip at 145% at 25 degrees C.Dielectric Strength: Over 1,500 volts RMS Max. Operating Voltages: 50VDC, 250VACInterrupt Capacity: 2,000 Amps at 50 VDC (1-30 amp Models) 1,000 Amps, at 250VAC (1-30 amp Models)

Read more less

Philmore B7015, Circuit Breaker, Push Button 15 Amps

Read more less

Philmore B7020, Push Button Thermal Circuit Breaker - 20 Amp B7000 series circuit breakers are UL 1077 Recognized as Supplementary protectors, File E99607, and CSA Certified as appliance components protectors, File LR62590. B7000 Series are single pole, thermal circuit breakers that feature a recessed rest button which cannot be manually pulled out to disconnect the circuit. When an overload occurs the breaker opens, it allows the rest button to "pop out" for visible trip indication. Specifications: Current Rating: 20A@ Max resistance in ohms: .006 Trip time @ 200% of rating: 6-30 seconds Endurance: 1,000 times + Calibration: Breaker will continuously carry 100% of rated load. It may trip between 101% and 144% of rated load, but must trip at 145% at 25 degrees C. Dielectric Strength: Over 1,500 volts RMS Max. Operating Voltages: 50VDC, 250VAC Interrupt Capacity: 2,000 Amps at 50 VDC (1-30 amp Models) 1,000 Amps, at 250VAC (1-30 amp Models)

Read more less

Philmore B7030, 30 Amp Push Button Circuit Breaker 32V DC or 250V AC Product Description:   Philmore circuit breakers are single pole, thermal circuit breakers that feature a recessed reset button which cannot be manually pulled out to disconnect the circuit. When an overload occurs and the breaker opens, it allows the reset button to “pop out” for visible trip indication. The recommended mounting hole is 0.437" (7/16"). Philmore circuit breakers are UL 1077 recognized as supplementary protectors, File E99607, and CSA Certified as appliance Components protectors, File LR62590. Endurance: 1,000 times at least. Calibration: Breaker will continuously carry 100% of rated load. It may trip between 101% and 144% of rated load, but must trip at 145% at 25º C. Dielectric Strength: Over 1,500 volts RMS. Max.   Philmore circuit breakers are single pole, thermal circuit breakers that feature a recessed reset button which cannot be manually pulled out to disconnect the circuit When an overload occurs and the breaker opens, it allows the reset button to pop out for visible trip indication For operation up to 32 volts DC or 250 volts AC. The recommended mounting hole is 0.437" (7/16") Philmore circuit breakers are UL 1077 recognized as supplementary protectors, File E99607, and CSA Certified as appliance Components protectors, File LR62590 Endurance: 1,000 times minimum Specifications:     Current Rating: 30A Max resistance in ohms: .004 Trip time @200% of rating 6-30 Seconds Endurance: 1,000 times at least Calibration: Breaker will continuously carry 100% of rated load. It may trip between 101% and 144% of rated load, but must trip at 145% at 25 degrees C. Dielectric Strength: Over 1,500 volts RMS Max. Operating Voltages: 50VDC, 250VAC Interrupt Capacity: 2,000 Amps at 50 VDC (1-30 amp Models) 1,000 Amps, at 250VAC (1-30 amp Models) 1/4" QC Terminals   Download the Philmore data sheet (.pdf)

Read more less
