Description
Rating: 30A, 300V
Distance between mounting holes: 7.88"
Center Spacing: .375" or 3/8" (9.52 mm)
Wire range: #14-22 AWG CU
Screw size: #6-32 philslot screws
Torque rating: 9 in-lb
Distance between barriers: .30" (7.62 mm)
Mounting: #6 screws
Operating temp.: 130°C (266°CF) Max., -40°C (-40°F) Min.
Molded base materials: Black, UL rated 94VO thermoplastic
Terminal plating: Tin over brass
Screws: Zinc plated steel
Agency information: UL/CSA; IEC Compliance; CE Certified
