Features:
- Point to Point RS-232/422/485 over Singlemode Fiber
- DCE/DTE selectable and 120 Ohm terminal resistor option
- Rugged IP30 enclosure and extended operating temperature range
- DIN-Rail & Wall Mountable installation options
- LED indicators showing data activity
Download Signamax MI00020 Quick Start Guide (.pdf)
Specifications:
APPLICABLE STANDARDS
IEEE 802.3 10BaseT
IEEE 802.3u 100BaseTX
IEEE 802.3x Flow Control
EIA/TIA-232/422/485
FIXED PORTS
DB9 (male) RS-232 port
4-pin Terminal block RS-422/485 port
Baud Rate: 50bps to 921.6 kbps
Data Bit: 5,6,7,8
Parity: None, Even, Odd, Space, Mark
Stop Bit: 1, 1.5, 2
ELECTRICAL CHARACTERISTICS
DC Input Power: 12-48 V DC Connected via dual redundant terminal block
5.5 x 2.5mm DC Barrel Jack connector provided
Power Consumption: 1.8W
Overload current protecion
PHYSICAL CHARACTERISTICS
Case Dimensions: 1.03” W x 2.76” D x 4.74”H (26 mm x 70 mm x 95 mm)
Housing: IP30 Metal Case
Weight: 0.42 lb ( 0.19 kg)
ENVIRONMENTAL REQUIREMENTS
Operating Temperature: -40°F to 167°F (-40°C to 75°C)
Storage Temperature: -40°F to 185°F (-40°C to 85°C)
Operating Humidity: 5% to 95% (non-condensing)
CERTIFICATIONS
CE, ROHS, FCC Class A
WARRANTY
Five Years
