Toggle Switches - Miniature

Philmore Mfg. 30-10014, DPDT, ON-(ON), Miniature Toggle Switch Current Rating: 5A @ 120V DC, 2A @ 250V AC Initial Contact Resistance: 2-4V DC 1A 10m ohm Insulation Resistance: 1000 Meg ohm (Min.) Dielectric Strength: 1000V RMS @ Sea Level Contact Material: Coin Silver - Silver Plate Terminal Material: Brass - Silver Plate Terminal Type: Solder  Action ON-(ON)  Actuator Metal Mounting Hole: 0.25"

Read more less

Philmore Mfg. 30-10008, SPDT, (ON)-OFF-(ON) Mini Toggle Switch Current Rating: 5A@ 120V AC/28V DC, 2A@ 250V AC Initial Contact Resistance: 2-4V DC 1A 10m ohm Insulation Resistance: 1000 Meg ohm (Min.) Dielectric Strength: 1000V RMS @ Sea Level Contact Material: Coin Silver - Silver Plate Terminal Material: Brass - Silver Plate Terminal Type: Solder  Action ON-ON  Actuator Metal Mounting Hole: .25"

Read more less

Philmore Mfg. 30-10022 3PDT ON-ON Miniature Toggle Switch The Philmore Mfg. 30-10022 is a 3PDT (Triple Pole Double Throw) miniature toggle switch featuring an ON-ON configuration. This switch is designed for reliable performance in various electrical applications, offering robust contact and terminal materials for durability and efficient operation. Features and Specifications Switch Type: 3PDT (Triple Pole Double Throw) Action: ON-ON Current Rating: 5A @ 120V AC/28V DC 2A @ 250V AC Initial Contact Resistance: 10 milliohms @ 2-4V DC 1A Insulation Resistance: 1000 Megohms (Min.) Dielectric Strength: 1000V RMS @ Sea Level Contact Material: Coin Silver - Silver Plate Terminal Material: Brass - Silver Plate Terminal Type: Solder Actuator: Metal Mounting Hole: 0.25" Installation Scenario The Philmore Mfg. 30-10022 toggle switch is ideal for use in electronic projects, control panels, and other applications requiring a reliable miniature toggle switch. For example, a technician installing a custom control panel for an industrial machine might use this switch to manage various control functions, benefiting from its high current rating and durable construction. Value for Installers and Technicians For installers and technicians, the Philmore Mfg. 30-10022 provides a reliable switching solution with high current capacity and excellent electrical characteristics. Its sturdy design and quality materials ensure long-term performance, making it a practical choice for a variety of demanding applications. The solder terminals allow for secure connections, enhancing overall system reliability.

Read more less

Philmore Mfg. 30-10032, 4PDT, ON-OFF-ON, Mini Toggle Switch Current Rating: 5A@ 120V AC/28V DC, 2A@ 250V AC Initial Contact Resistance: 2-4V DC 1A 10m ohm Insulation Resistance: 1000 Meg ohm (Min.) Dielectric Strength: 1000V RMS @ Sea Level Contact Material: Coin Silver - Silver Plate Terminal Material: Brass - Silver Plate Terminal Type: Solder Action ON-OFF-ON Actuator Metal Mounting Hole: .25"

Read more less

Philmore Mfg. 30-10034, 4PDT, ON-ON, Mini Toggle Switch Current Rating: 5A@ 120V AC/28V DC, 2A@ 250V AC Initial Contact Resistance: 2-4V DC 1A 10m ohm Insulation Resistance: 1000 Meg ohm (Min.) Dielectric Strength: 1000V RMS @ Sea Level Contact Material: Coin Silver - Silver Plate Terminal Material: Brass - Silver Plate Terminal Type: Solder Action ON-ON Actuator Metal Mounting Hole: .25"

Read more less

Philmore 30-090 DPDT ON-ON-ON Miniature Toggle Switch Product Overview: The Philmore 30-090 is a versatile DPDT (Double Pole Double Throw) ON-ON-ON miniature toggle switch, designed for a variety of low-voltage applications. Known for its reliability and compact size, this switch is ideal for use in electronic projects, instrumentation, and control panels where space is a premium. Tri-Tek Electronics is an authorized distributor of Philmore products, ensuring full manufacturer warranty coverage, best pricing, and factory support. Product Features: Configuration: DPDT (Double Pole Double Throw) Operation Type: ON-ON-ON Mounting Style: Panel mount Actuator Type: Bat style Terminal Type: Solder lug Contact Material: Silver alloy Electrical Rating: 3A at 250V AC Insulation Resistance: 100MΩ at 500V DC Dielectric Strength: 1500V AC for 1 minute Mechanical Life: 50,000 cycles Contact Resistance: 20mΩ max Dimensions: 12.7mm (0.5") panel cutout diameter Specifications: Parameter Specification Model Number 30-090 Switch Type Toggle Operation Positions ON-ON-ON Poles and Throws DPDT Contact Rating 3A at 250V AC Contact Material Silver alloy Insulation Resistance 100MΩ at 500V DC Dielectric Strength 1500V AC for 1 minute Mechanical Life 50,000 cycles Panel Cutout Diameter 12.7mm (0.5") Termination Style Solder lug Actuator Style Bat Applications: The Philmore 30-090 toggle switch is suitable for a range of applications, including: Electronic Projects: Ideal for DIY electronics and hobby projects requiring a reliable switch. Control Panels: Perfect for control panels where multiple switching options are needed in a compact space. Instrumentation: Suitable for use in various instruments requiring precise switch control. Example Installation Scenario: An electronics technician might use the Philmore 30-090 in a custom control panel for a home automation system. The switch’s DPDT ON-ON-ON functionality allows the technician to control different modes of operation for various connected devices, such as lights, fans, or other automated systems. The compact size of the switch ensures that it fits neatly into the panel without taking up excessive space, making the installation both efficient and professional. Benefits for Installers and Technicians: Compact Design: Easy to fit in tight spaces within control panels and enclosures. High Reliability: Durable construction ensures long-term performance and minimal maintenance. Versatility: Multiple switching positions allow for diverse application scenarios. Ease of Installation: Solder lug terminals facilitate straightforward wiring and secure connections. Manufacturer Information: Philmore Manufacturing offers a wide range of electronic components and accessories designed to meet the needs of professionals and hobbyists alike. As an authorized distributor, Tri-Tek Electronics ensures that customers receive genuine Philmore products with full warranty coverage and exceptional factory support. Product Documentation: Philmore 30-090 Product Specifications

Read more less

Philmore Mfg. 30-10018, DPDT (ON)-OFF-(ON) Miniature Toggle Switch Current Rating: 5A @ 120V AC/28V DC, 2A @ 250V AC Initial Contact Resistance: 2-4V DC 1A 10m ohm Insulation Resistance: 1000 Meg ohm (Min) Dielectric Strength: 1000V RMS @ Sea Level Contact Material: Coin Silver - Silver Plate Terminal Material: Brass - Silver Plate Terminal Type: solder Action (ON)-OFF-(ON) Actuator Metal Mounting Hole: 0.250"

Read more less

Philmore 30-10002 Miniature SPDT ON-ON Toggle Switch Product Overview: The Philmore 30-10002 is a mini Single Pole Double Throw (SPDT) ON-ON toggle switch, designed for a variety of low-voltage applications. Its compact design and reliable performance make it suitable for use in electronic projects, control panels, and other applications where space and reliability are critical. Tri-Tek Electronics is an authorized distributor of Philmore products, ensuring full manufacturer warranty coverage, best pricing, and factory support. Product Features: Configuration: SPDT (Single Pole Double Throw) Operation Type: ON-ON Mounting Style: Panel mount Actuator Type: Bat style Terminal Type: Solder lug Contact Material: Silver alloy Electrical Rating: 6A at 125V AC, 3A at 250V AC Insulation Resistance: 1,000MΩ at 500V DC Dielectric Strength: 1,500V AC for 1 minute Mechanical Life: 50,000 cycles Contact Resistance: 20mΩ max Dimensions: 6.35mm (0.25") panel cutout diameter Specifications: Parameter Specification Model Number 30-10002 Switch Type Toggle Operation Positions ON-ON Poles and Throws SPDT Contact Rating 6A at 125V AC, 3A at 250V AC Contact Material Silver alloy Insulation Resistance 1,000MΩ at 500V DC Dielectric Strength 1,500V AC for 1 minute Mechanical Life 50,000 cycles Panel Cutout Diameter 6.35mm (0.25") Termination Style Solder lug Actuator Style Bat Applications: The Philmore 30-10002 toggle switch is suitable for a range of applications, including: Electronic Projects: Ideal for DIY electronics and hobby projects requiring a reliable switch. Control Panels: Perfect for control panels where multiple switching options are needed in a compact space. Instrumentation: Suitable for use in various instruments requiring precise switch control. Example Installation Scenario: An electronics technician might use the Philmore 30-10002 in a custom control panel for a small automation project. The switch’s SPDT ON-ON functionality allows the technician to control two different circuits with a single switch. The miniature size of the switch ensures it fits neatly into the panel without taking up much space, providing a clean and efficient installation. Benefits for Installers and Technicians: Compact Design: Ideal for installations where space is limited. High Reliability: Robust construction ensures long-lasting performance and minimal maintenance. Versatility: ON-ON operation supports diverse application needs. Ease of Installation: Solder lug terminals facilitate straightforward wiring and secure connections.
