Snap-Action Switches

Philmore 30-1307 H.D. Snap Action Switch with Plunger, SPDT Overview: Tri-Tek Electronics is an authorized distributor of Philmore products, ensuring full manufacturer warranty coverage, best pricing, and factory support. The Philmore 30-1307 Heavy Duty Snap Action Switch is a Single Pole Double Throw (SPDT) switch designed for durability and reliable performance. It features a momentary snap action with a plunger, making it suitable for a wide range of electrical applications. Features and Specifications: Type: Heavy Duty Snap Action Switch with Plunger Operation: Snap Action Momentary Current Rating: 15A @ 125/250V AC 1/2A @ 125V DC 1/4 HP @ 250V DC 1/8 HP @ 125V AC 1/4 HP @ 250V AC Initial Contact Resistance: 15 Meg ohm (Max) Insulation Resistance: 100 Meg ohms (Min) @ 500V DC Dielectric Strength: 1000V AC for 1 minute Contact Material: Silver Terminal Material: Brass - Silver Plate Terminal Type: Screw Mounting Hole: Standard size for snap action switches Example Installation Scenario: This snap action switch is ideal for use in industrial control systems where a reliable momentary contact is essential. It can be installed in control panels, machinery housings, or other equipment requiring a robust switch with a snap action. The brass screw terminals ensure secure and easy connections, and the plunger actuator provides a precise and responsive switch operation. Value for Installers and Technicians: For installers and technicians, the Philmore 30-1307 switch offers reliability and ease of installation. The snap action momentary operation ensures straightforward usage, and its high current rating allows it to handle demanding applications. The switch's robust construction and high-quality materials ensure long-term durability and performance.

Read more less

ZF (Cherry) 0E1300M0 Single Pole General Purpose Snap Action Switch Cherry 0E1300M0, Snap Action Switch 15A 250VAC Overall Dims (In): 1.8 x 0.7 x 0.7 3 contact configurations 3 terminal types (optional screw terminals available) Wide variety of auxiliary actuators available 5 current ratings, up to 30 A Robust standard switch for industrial applications High-temperature 150 °C (200 °C on request) Long-life coil spring mechanism Enhance your industrial applications with the Cherry 0E1300M0 Snap Action Switch, renowned for its robustness and versatility. This switch supports a maximum rating of 15A at 250VAC and features a compact design with dimensions of 1.8 x 0.7 x 0.7 inches. Ideal for diverse operating environments, it offers a high temperature tolerance of up to 150 °C, with an option to extend to 200 °C upon request. The 0E1300M0 is equipped with three contact configurations and three terminal types, with screw terminals available as an option. It also accommodates a wide variety of auxiliary actuators, making it a highly adaptable choice for numerous industrial settings. This model is specifically engineered to deliver long-lasting performance with its durable coil spring mechanism and is available in five different current ratings, up to 30 A. Please note that this is a closeout item, and availability is limited to stock on hand, ensuring exclusive pricing for our remaining inventory.

Read more less

Philmore Mfg. 30-1701, SPDT, Snap Action Momentary, H.D. Switch w/Long Lever Current Rating: 15A @ 125/250V AC, 1/2A @ 125V DC, 1/4 HP @ 250V DC, 1/8 HP @ 125V AC, 1/4 HP @ 250V AC Initial Contact Resistance: 15 Meg ohm (Max.) Insulation Resistance: 500V DC 1000 Meg ohm (Min.) Dielectric Strength: 1000V AC for 1 minute. Contact Material: Silver Terminal Material: Brass - Silver Plate Terminal Type: Screw Action Snap Action Momentary Actuator Long Lever Mounting Hole:

Read more less

Philmore Mfg. 30-2505, SPDT, Snap Action Momentary, Sub-Miniature Switch w/Roller Lever Current Rating: 5A@ 125V AC, 3A @ 250V AC Initial Contact Resistance: 15 Meg ohm (Max) Insulation Resistance: 500V DC 1000Meg ohm (Min) Dielectric Strength: 1000V AC for 1 minute Contact Material: Silver Terminal Material: Brass - Silver Plate Terminal Type: Solder Action Snap Action Momentary Actuator Roller Lever Mounting Hole: 0.203"

Read more less

Philmore Mfg. 30-18230, SPDT, Miniature Snap Action Switch with Pin Plunger Current Rating: 16A @ 125V/250V AC Initial Contact Resistance: 15 Meg ohm (Max) Insulation Resistance: 500V DC 1000 Meg ohm (Min) Dielectric Strength: 1000V AC for 1 minute Contact Material: Silver Terminal Material: Brass - Silver Plate Terminal Type: .187" Quick Connect Action Snap Action Momentary Actuator Pin Plunger Mounting Hole:                     Note: Rated 10A @ 125V/250VAC with .250" Quick Connect

Read more less

Philmore Mfg. 30-18222 SPDT, ON-ON Sub Miniature Snap Action Switch With Long Lever Snap action switches have a common input and both normally closed (NC) and normally open (NO) outputs. Current Rating: 5A @ 125V AC, 3A @ 250V AC Initial Contact Resistance: Under 30 Meg ohm Insulation Resistance: 100 Meg ohm (Min) Dielectric Strength: 1000V AC 50-60 Hz Service Life: Mechanically 30,000,000 Electricity 100,000 Terminal Material:   Terminal Type: Solder  Action Snap Action Momentary  Actuator Long Lever Mounting Hole:

Read more less

Philmore Mfg. 30-2000, SPDT Mini Snap Action Switch 16A@125V Pin Plunger   Current Rating: 16A @ 125V/250V AC Initial Contact Resistance: 15 Meg ohm (Max) Insulation Resistance: 500V DC 1000 Meg ohm (Min) Dielectric Strength: 1000V AC for 1 Minute Contact Material: Silver Terminal Material: Brass - Silver Plate Terminal Type: .187" Quick Connect Action Snap Action Momentary Actuator Pin Plunger Mounting Hole:

Read more less
