Cat 6 / 6A / 7 Keystone Jacks

High-End Product Description: Electrical Performance IDC Contact Resistance: Exceptionally low at a maximum of 2.5 mOhm. Current Rating: Consult the downloadable spec sheet for precise details. Premium Construction Housing: Crafted from high-impact thermoplastic, ensuring UL94V-0 fire retardancy for added safety. Jack Spring Wire: Precision-made from a phosphor bronze alloy, plated with an opulent 50 μin of gold over 70 to 100 μin of nickel. IDC: Utilizes a 110-type design with a phosphor bronze alloy and is coated with a lavish 100 μin 100% tin alloy. Mechanical Excellence Total Contact Force: Guarantees a minimum of 800 g for 8 wire leads, ensuring robust and reliable connections. Retention: Securely holds at 50 N (11 lbf) for 60 ± 5 seconds, delivering unwavering stability. Mating Cycle Life: Boasts a minimum of 750 cycles, ensuring long-lasting performance. Standard Keystone Footprint FOOTPRINT: Adheres to the industry-standard keystone footprint for seamless integration. Precision Mounting Dimensions MOUNTING DIMENSIONS: Precisely measures 1.18” D x 0.67” W x 0.76” H (30.0 mm x 16.9 mm x 19.3 mm) for effortless installation. Environmental Resilience Operating Temperature: Capable of operating flawlessly within a wide temperature range, from 14 °F to 140 °F (-10 °C to 60 °C). Storage Temperature: Designed to withstand extreme conditions, with a storage range of -40 °F to 158 °F (-40 °C to 70 °C). Operating RH: Maintains peak performance even in environments with up to 93% humidity (non-condensing). Stringent Compliance COMPLIANCE: Meets or exceeds the most rigorous industry standards, including ANSI/TIA-568-C.2, IEEE 802.3 ab, IEEE 802.3 af/at/bt, IEC 60512-99-002, FCC Part 68 Subpart F, and UL 94V-0, ensuring top-notch quality and safety. Versatile Applications APPLICATIONS: Suitable for an array of high-end networking applications, including X.21, V.11, S0, ISDN, CSMA/CD 10BASE-T, 100BASE-TX, 100BASE-T4, 100BASE-T2, 1000BASE-T, 10GBASE-T, TR 4/16/100, 100BASE-VG, ATM LAN 25/51/155, and TP-PMD. Exceptional Warranty WARRANTY: Backed by a 5-year Limited Component Warranty and an impressive 25-year Signamax Cabling System Warranty, ensuring your investment is protected and supported for the long haul.

Read more less

Latest in High-Speed Networking: Signamax Category 6 MT-Series Unscreened Keystone Jacks Embrace the future of networking with the advanced Signamax Category 6 MT-Series Unscreened Keystone Jacks, expertly crafted for high-bandwidth applications. These slim-profile connectors are the perfect fit for the most densely packed network setups, offering the versatility of color-coded service identification icons or dust covers to ensure protection against environmental contaminants. Innovatively designed for enhanced connection integrity, these jacks are resilient against damage from 4- or 6-position plug insertions. Their unique construction enables termination with either a standard 110 single-position tool or the specialized Signamax four-pair tool. Rated for at least 750 plug insertions, these jacks promise unparalleled system reliability. Master Pack - Comprehensive Networking Solution: This all-in-one pack is essential for setting up 500 jacks in work areas or telecommunication racks. The robust HDPE resealable bucket includes: 500 MT Series Keystone Jacks One MT-Series termination tool An organizer tray A complimentary Signamax T-Shirt Standout Features: Surpasses TIA-568-C.3 component performance standards. Designed for high-density network environments. Enhanced wire retention and straightforward termination with rear 110 type contacts. Supports power-over-Ethernet (PoE) applications: IEEE 802.3af, 802.3at, and IEEE 802.3bt type 3 and 4. Fully compatible with Signamax screened snap-in patch panels and work area faceplates. Includes circuit identification icons, dust covers, and 110 protection caps. Technical Specifications at a Glance: Transmission Performance: Meets/exceeds Category 6 (1-250 MHz) standards as per ANSI/TIA-568-C.2. Jack Type: 8p8c (8-position, 8-contact) “RJ45” style. Wiring Scheme: T568A & T568B; ISO/IEC 11801 2nd Ed. compliant. Robust Construction and Compliance: Housing: High-impact thermoplastic, UL94V-0 fire retardant. Jack Spring Wire: Phosphor bronze alloy, gold and nickel plated. IDC: 110 type, phosphor bronze alloy with tin alloy. Environmental and Mechanical Durability: Operating Temperature Range: 14 °F to 140 °F (-10 °C to 60 °C). Storage Temperature Range: -40 °F to 158 °F (-40 °C to 70 °C). Mating Cycle Life: Minimum 750 cycles. Compliance Standards: Meets ANSI/TIA-568-C.2, IEEE 802.3 standards, and more. Applications and Warranty: Suitable for a wide range of applications including X.21, V.11, ISDN, CSMA/CD 10BASE-T, and others. Comes with a 5-year Limited Component and a 25-year Signamax Cabling System Warranty.

Read more less

Signamax KJS458TL-C6C Cat 6 Shielded Toolless Keystone Jack The Signamax KJS458TL-C6C is a Category 6 shielded toolless keystone jack designed to meet the demands of high-bandwidth applications. Its compact profile and integrated termination cap facilitate high-density installations without the need for specialized tools. The robust shielding ensures reliable performance in environments with elevated electromagnetic interference (EMI). Key Features Exceeds ANSI/TIA-568-C.2 Specifications: Ensures superior performance for Category 6 applications. 360-Degree Shielding: Provides comprehensive protection against EMI, maintaining signal integrity. Toolless Termination: Integrated termination cap allows for quick and secure connections without specialized tools. T568A/B Wiring Compatibility: Supports both wiring schemes, offering flexibility in installation. High Durability: Rated for a minimum of 750 plug insertions, ensuring long-lasting reliability. Slim Profile: Ideal for high-density applications, compatible with Signamax screened snap-in patch panels and work area faceplates. Specifications Specification Details Category 6 Shielding Yes Termination Method Toolless with integrated cap Wiring Scheme T568A/B Contact Material Phosphor bronze alloy with 50 µin gold over 70–100 µin nickel Housing Material Zinc-alloy fully shielded Insertion Durability Minimum 750 plug insertions Compatibility Signamax screened snap-in patch panels and work area faceplates Standards Compliance ANSI/TIA-568-C.2, IEEE 802.3an 10 Gigabit Ethernet Installation Scenario Ideal for environments requiring high-density cabling solutions, such as data centers and telecommunications rooms, the KJS458TL-C6C ensures efficient and reliable network connections. Its toolless design simplifies installation, reducing labor time and costs. The comprehensive shielding makes it suitable for areas with significant EMI, ensuring consistent performance. Authorized Distributor Tri-Tek Electronics, located in Mesa, AZ, is an authorized distributor of Signamax products. Purchasing from Tri-Tek ensures full manufacturer warranty coverage, competitive pricing, and access to factory support.

Read more less

Dynacom 10606AS Shielded Cat6A Data Jack - Tool-less *** PLEASE ORDER IN MULTIPLES OF 20 PCS.*** The Dynacom 10606AS Shielded Cat6A Data Jack is a high-performance, tool-less Ethernet jack designed to deliver exceptional connectivity for high-speed data transmission. This robust, easy-to-install component is essential for professionals seeking reliable and efficient network setups, particularly in environments with significant electromagnetic interference (EMI). As an authorized distributor, Tri-Tek Electronics provides full manufacturer warranty coverage and ensures the best pricing and factory support for the Dynacom 10606AS. This makes it an ideal choice for both installers and end-users looking for quality and dependability in their network components. Key Features Tool-less Installation: Simplifies setup, requiring no special tools. Category 6A Performance: Supports high-speed data transmission up to 10 Gbps. Shielded Design: Provides excellent protection against EMI and crosstalk. Universal Wiring: Compatible with T568A and T568B wiring schemes. Compact and Durable: Ideal for high-density installations with a rugged design. 360° Shielding: Ensures consistent performance by eliminating external interference. Gold-Plated Contacts: Enhances signal quality and durability. Specifications Specification Details Category Cat6A Type Shielded, Tool-less Transmission Speed Up to 10 Gbps Housing Material Zinc Alloy Shielding 360° Shielding Wiring Compatibility T568A/B Contact Material Gold-Plated Color Metallic Silver Operating Temperature -40°C to 85°C Compliance ANSI/TIA-568.2-D, ISO/IEC 11801 Example Installation Scenario Scenario: A data center requires robust cabling infrastructure to support its high-speed servers and networking equipment. The Dynacom 10606AS Shielded Cat6A Data Jack is an ideal choice for this environment due to its tool-less installation and superior shielding. The IT team quickly installs the jacks into patch panels and wall plates without needing additional tools, ensuring minimal downtime. The jack’s shielding effectively eliminates interference, allowing the data center to maintain optimal performance even in an EMI-rich environment. Product Applications Data Centers: For high-speed, interference-free connections. Office Networks: Ideal for gigabit Ethernet and beyond. Industrial Settings: Suitable for environments with high EMI. Telecommunications: Ensures reliable and high-quality voice and data transmission. Installation Guide Preparation: Ensure that you have the required cables and confirm the length. Cable Stripping: Strip about 1.5 inches of the cable jacket and separate the twisted pairs. Wiring: Follow the color-coded labels on the jack for either T568A or T568B configuration. Termination: Insert the wires into the jack according to the color code. Securing: Close the jack cover to secure the wires and ensure a tight fit. Testing: Use a cable tester to verify the connection.

Read more less

Triplett CAT7-KJSWH-10PK Category 7 Compact Shielded Keystone Jacks, Metallic, 10 Pack The Triplett CAT7-KJSWH-10PK is a high-performance 10-pack of shielded keystone jacks designed specifically for Category 7 Ethernet applications. These compact jacks are engineered for demanding network environments that require top-tier data integrity, shielding, and bandwidth capabilities. Category 7 cable infrastructure supports transmission frequencies up to 600 MHz and data rates up to 10 Gbps (10 Gigabit Ethernet) over 100 meters of copper cabling, making it ideal for high-speed, high-bandwidth network backbones and data-intensive applications. Constructed with a robust metallic housing and precision-machined components, the CAT7-KJSWH-10PK jacks provide excellent EMI/RFI protection and are compatible with shielded twisted pair (STP) cable. Each jack supports 22–26 AWG solid conductor cables and is designed to maintain shielding continuity from the cable to the connector, preserving full Cat 7 compliance throughout the installation. Tri-Tek Electronics, an authorized distributor of Triplett products, offers this keystone jack 10-pack with full factory warranty and support. Available now at our Mesa, AZ retail location, where local installers and integrators can find expert support and rapid product availability. Key Features: Category 7 Compliant – Rated for transmission speeds up to 10 Gbps and bandwidth up to 600 MHz Shielded Compact Design – Provides superior protection against electromagnetic interference (EMI) and crosstalk Standard Keystone Form Factor – Fits standard patch panels, wall plates, and surface mount boxes Premium Build Quality – Metallic housing, phosphor bronze contacts with 50µ gold plating for long-term durability Wire Gauge Support – Accommodates 22–26 AWG solid wire; insulation diameter 0.4–0.6 mm White Housing – Clean and professional appearance Pack Quantity – Includes 10 shielded keystone jacks per package Common Applications: Data Centers – Reliable high-speed connections between servers and core switches Commercial Networks – Office environments with VoIP, high-definition video conferencing, and data-intensive software Home Automation – High-bandwidth backbone for smart home control systems, streaming, and 10GbE-capable devices Industrial Environments – EMI-resistant terminations for network equipment in electrically noisy settings Installation Scenario: In a modern commercial office undergoing a network infrastructure upgrade, installers select the Triplett CAT7-KJSWH-10PK to terminate shielded Cat 7 cabling between network switches and workstation outlets. The superior EMI shielding and high bandwidth ensure flawless data transmission for applications such as cloud computing, HD video streaming, and real-time collaboration platforms. Their compact keystone format streamlines panel and wall plate layout, saving space while delivering enterprise-grade performance.

Read more less

Vertical Cable 352-V2715/GR Green Cat 6 110-Style Keystone Jack The Vertical Cable 352-V2715/GR is a high-performance Cat 6 keystone jack designed for 110-style punch-down termination. This green keystone jack is ideal for Ethernet, voice, and data transmission in commercial and residential network installations. Its sturdy construction and compliance with Cat 6 standards ensure that it delivers reliable, high-speed performance while maintaining signal integrity for gigabit networks. As an authorized distributor of Vertical Cable products, Tri-Tek Electronics offers this keystone jack with full manufacturer warranty and factory support. Key Features: Type: Cat 6 110-style keystone jack Color: Green, easy color coding for network organization Category: Cat 6, supporting gigabit Ethernet and high-speed data transmission Durability: Sturdy housing ensures long-term reliability Easy Termination: 110-style punch-down design for quick and secure cable installation Compatibility: Fits standard keystone wall plates, patch panels, and surface mount boxes Standards Compliance: Meets or exceeds TIA/EIA-568-C.2 standards for Category 6 Example Installation Scenario: The Vertical Cable 352-V2715/GR is perfect for use in office buildings, data centers, and residential networks where high-speed, reliable connectivity is required. It can be used in patch panels, wall plates, or surface-mount boxes to provide seamless Ethernet connections for computers, VoIP phones, and other network devices. Specifications: Category: Cat 6 Termination Type: 110 punch-down Color: Green Standards: TIA/EIA-568-C.2 compliant Compatibility: Works with Cat 6 and backward compatible with Cat 5e Tri-Tek Electronics in Mesa, AZ, offers the Vertical Cable 352-V2715/GR Cat 6 keystone jack with full manufacturer warranty and technical support for professional network installations.

Read more less

Vertical Cable 078-2150 I-Punch Tool for V-Max Keystone Jack Series The Vertical Cable 078-2150 I-Punch Tool is specifically designed for quick and easy termination of the V-Max Keystone Jack Series, making cable installation as simple as 1-2-3. This tool is perfect for installers working with Cat 3, Cat 5e, and Cat 6 V-Max jacks, ensuring efficient, high-quality terminations without the need for complex tools or additional accessories. Key Features: Material: Constructed from high-grade carbon steel with a black oxide finish for enhanced durability and long-term use Blade: Made of alloy steel, designed to provide precise, clean cuts without the need for a replacement blade Handle Mechanism: Locking Function: To lock the handles in a parallel position, gently squeeze the handles together without closing them completely; they will stay locked in place. Release Function: To unlock, squeeze the handles all the way, and the handles will release. Compatibility: Specifically designed for use with Vertical Cable's V-Max Keystone Jacks (Cat 3, Cat 5e, Cat 6). This ensures the best performance when terminating these jacks, providing reliable connections and preventing errors during installation. Example Installation Scenario: Ideal for professional network installers, the I-Punch tool simplifies the task of terminating multiple V-Max Keystone Jacks during a large office or data center installation. With its intuitive design and no need for replacement blades, the tool reduces downtime and maintenance costs, making it a must-have for technicians working on structured cabling projects. Specifications: Material: Carbon Steel with Black Oxide Finish Blade: Alloy Steel (no replacement needed) Compatibility: Works with Vertical Cable V-Max Keystone Jacks (Cat 3, Cat 5e, Cat 6) Usage Instructions: Locking Handles: Slowly squeeze handles until they lock in parallel. Unlocking Handles: Squeeze handles completely to release. Tri-Tek Electronics in Mesa, AZ, proudly offers the Vertical Cable 078-2150 I-Punch Tool, ensuring full manufacturer warranty and factory support for all your installation needs.

Read more less

- High-quality CAT6 Jacks for reliable network connections - Pack of 25 pieces for multiple installations - Easy to use and install with KwikPak packaging Upgrade your network installations with the Dynacom 10606K25-OR CAT6 Jacks in vibrant orange. Designed for electronics technicians, IT professionals, and low voltage installers, these jacks offer exceptional performance and value. 🔹 Pack of 25 CAT6 Jacks for multiple installations 🔹 Easy to use and install with KwikPak packaging 🔹 High-quality construction ensures reliable network connections Specifications: - Brand: Dynacom - Model: 10606K25-OR - Colour: Orange - Quantity: 25 pieces Tri-Tek Electronics is proud to be an authorised distributor of Dynacom products, ensuring you receive genuine items with unmatched quality and performance. Upgrade your network installations with confidence today!

Read more less

- High-quality CAT6 jacks for reliable network connections - Pack of 25 pieces for convenience in large installations - Easy and quick installation with KwikPak packaging Upgrade your network installations with Dynacom 10606K25-BK CAT6 jacks. 🚀 🔗 Tri-Tek Electronics is an authorised distributor of Dynacom products, ensuring you receive top-notch quality and performance. 🔗 Designed for electronics technicians, IT professionals, and low voltage installers, these CAT6 jacks offer exceptional value and performance. Here's why they're a must-have for your next project: ⚙️ Specifications: - Type: CAT6 - Colour: Black - Quantity: 25 pieces - Packaging: KwikPak for quick and easy installation 🔧 Features: - High-quality construction for reliable network connections - Pack of 25 pieces for convenient large installations - KwikPak packaging for easy and quick installation Elevate your network setup with Dynacom 10606K25-BK CAT6 jacks and experience seamless connectivity like never before. Trust Tri-Tek Electronics for all your Dynacom needs and enjoy the benefits of working with an authorised distributor.

Read more less

Signamax KJS458IG-C6C Category 6 Shielded Industrial Grade Jack with Protective Cap, IP67 Rated The Signamax KJS458IG-C6C is a Category 6 shielded industrial-grade jack engineered to deliver superior transmission performance in demanding environments. Its robust construction and IP67 rating ensure reliable connectivity in settings such as factory floors, chemical plants, and food processing facilities. Key Features IP67-Rated Housing: Provides exceptional protection against dust and water ingress, ensuring durability in harsh conditions. Shielded Design: Offers enhanced protection against electromagnetic interference (EMI), maintaining signal integrity. Protective Cap: Includes a dust cap to safeguard the jack when not in use, preventing contamination and damage. T568A/B Wiring Compatibility: Supports both T568A and T568B wiring schemes, offering flexibility in installation. Standard 110 Termination: Compatible with standard single-position 110 termination tools, facilitating easy and secure connections. High Durability: Rated for at least 750 plug insertions, ensuring long-lasting performance. Specifications Specification Details Category 6 Shielding Yes IP Rating IP67 Wiring Scheme T568A/B Termination Standard 110 tool Insertion Durability Minimum 750 plug insertions Housing Material Industrial-grade, robust construction Protective Cap Included Installation Scenario Ideal for industrial environments where exposure to dust, moisture, and electromagnetic interference is prevalent, the KJS458IG-C6C ensures reliable network connections. Its IP67 rating and shielded design make it suitable for installations in factory floors, chemical processing plants, and outdoor applications requiring robust connectivity solutions. Authorized Distributor Tri-Tek Electronics, located in Mesa, AZ, is an authorized distributor of Signamax products. Purchasing from Tri-Tek ensures full manufacturer warranty coverage, competitive pricing, and access to factory support.
